2024 Honda TRX420 RANCHER at Tri-Town Motorsports

Standard

• Transmission: Five-speed with automatic clutch, reverse and ultra-low first gear
• Engine Type: Liquid-cooled longitudinally mounted single-cylinder
• Valve Train: OHV, 2 valves
• Fuel Delivery: PGM-FI electronic fuel injection
• Displacement: 420 cc
• Bore & Stroke: 86.5 mm x 71.5 mm
• Compression Ratio: 9.9:1
• Final Drive: 2WD/4WD; direct front and rear driveshafts with 2WD/4WD shifter and torque-sensing front differential

Standard

• Warranty: 12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus
• Colour: Avenger Red
• Tires: Front: 24 x 8-12v Rear: 24 x 10-11
• Brakes: Front: dual 190 mm discs / Rear: 160 mm sealed mechanical drum
• Length: 2,104 mm (82.8 in.)
• Width:1,205 mm (47.4 in.)
• Ground Clearance:181 mm (7.1 in.)
• Wheelbase: 1,269 mm (50 in.)
• Curb Weight: 278 kg (612 lb.)
• Fuel Capacity: 14.7 litres, including 4.9 litre reserve
• Cargo capacity: Front rack: 30 kg (66 lb.) / Rear rack: 60 kg (133 lb.)
• Towing capacity:385 kg (850 lb.)

Standard

• Front Suspension: Independent Double A-arm with adjustable hydraulic shocks; 170 mm (6.7 in.) travel
• Rear Suspension: Swingarm with single adjustable hydraulic shock; 170 mm (6.7 in.) travel
